Choosing The Right Turbo
One of the biggest misconceptions when choosing a turbocharger is that moving to the largest available option automatically produces the best-performing car.
In reality, turbo selection is about matching airflow, response, efficiency, and power potential to the engine, ECU strategy, supporting modifications, and intended use of the vehicle.
A properly matched turbocharger will:
• Reach boost sooner
• Deliver stronger transient response
• Maintain power more consistently
• Operate with less unnecessary shaft speed and heat
• Produce a broader, more usable powerband
• Be easier for the ECU and boost-control system to manage
The best turbo is not always the one capable of producing the highest peak number. It is the turbo that operates most efficiently within the airflow range your engine can realistically use.
Understanding the Pro Xe P1 Hybrid Lineup
The PX350, PX380, PX400, and PX600 were developed for different power goals. Each step increases airflow capacity, but it also changes spool characteristics, supporting-modification requirements, and the way the vehicle delivers power.
PX350 — Maximum Response and Street Drivability
The PX350 is designed for drivers who want quicker response, stronger midrange torque, and improved efficiency without sacrificing the fast-spooling characteristics of the factory K04.
It uses an OEM-sized lightweight billet compressor wheel paired with an OEM-diameter, high-efficiency lightweight turbine wheel. Rather than relying on significantly oversized wheels, the PX350 improves performance through reduced rotating mass, extensive housing porting, and optimized internal airflow.
The PX350 is best suited for:
• Daily-driven and street-focused builds
• Drivers who prioritize response over peak horsepower
• Automatic or manual cars that benefit from early torque
• Basic bolt-on combinations using pump gas
• Builds targeting approximately 320+ HP, depending on fuel and supporting modifications
For many street cars, the PX350 will feel faster more often because it responds immediately and produces power throughout the RPM range where the vehicle is normally driven.
PX380 — The Balanced Street Performance Option
The PX380 is the middle ground between instant K04 response and increased top-end airflow.
Its oversized 7+7 extended-tip billet compressor is paired with an upgraded 9-blade cutback turbine. This combination provides substantially more airflow than the PX350 while retaining fast spool, strong midrange response, and OEM-style drivability.
The PX380 is best suited for:
• Full bolt-on street cars
• Drivers seeking approximately 350+ HP
• Builds that need stronger top-end performance without excessive lag
• Customers who want a balance of response, torque, and airflow
• Pump-gas or ethanol-fueled combinations with proper tuning and fueling upgrades
For most performance-oriented P1 street builds, the PX380 offers one of the best overall balances between spool, airflow, and usable power.
PX400 — Maximum Performance From the K04 Frame
The PX400 is the highest-flowing K04-based turbocharger in the Pro Xe P1 lineup.
It uses a larger 11+0 extended-tip billet compressor wheel paired with an oversized clipped 9-blade cutback turbine. The turbine housing receives substantially more aggressive modifications, including an enlarged volute and throat, maximum wastegate and outlet porting, and smoothed flow paths throughout the assembly.
The PX400 is best suited for:
• High-output K04 builds
• Drivers targeting approximately 370+ hp
• Vehicles equipped with upgraded fueling and cooling systems
• Engines with block shims or additional internal reinforcement
• Customers who want maximum top-end performance while retaining K04 fitment
The PX400 sacrifices some of the immediate response of the smaller options in exchange for greater airflow and high-RPM power. It is the correct choice for someone trying to extract everything possible from the factory K04 footprint.
PX600 — When the K16 Frame Makes Sense
The PX600 is intended for builds that have moved beyond what the K04 housing can efficiently support.
Built around the larger Focus RS Mk2 K16 frame, the PX600 offers significantly greater compressor and turbine-side capacity. Its larger housing and rotating assembly provide the airflow headroom required for serious high-horsepower combinations.
The PX600 is best suited for:
• Built-engine or motorsport-oriented projects
• Drivers targeting power beyond the practical K04 range
• High-boost and high-RPM combinations
• Vehicles with upgraded fuel systems, intercoolers, exhaust systems, clutches, and engine internals
• Builds targeting approximately 550+ BHP with the proper supporting modifications and calibration
The PX600 will not respond as quickly as a PX350 or PX380, but it is not designed for the same purpose. Its advantage is the ability to continue moving air efficiently after the K04 housing has reached its practical flow limit.
K04 Versus K16: Choose Based on the Build
A K16 is not automatically better than a hybrid K04, and a hybrid K04 is not automatically better than a K16. Each platform has an operating range where it performs best.
K04-Based PX350, PX380 and PX400 Advantages
• Faster spool and transient response
• Lower rotating inertia
• Stronger low- and midrange performance
• Easier boost and torque management
• OEM-style installation and drivability
• Better performance for moderate street-power goals
K16-Based PX600 Advantages
• Greater overall airflow capacity
• More turbine-side flow headroom
• Reduced drive-pressure limitations at high airflow levels
• Stronger high-RPM power potential
• Better suited for built engines and serious peak-power goals
For most street-driven P1 cars, the PX350, PX380, or PX400 will produce a broader and more accessible powerband. The PX600 becomes the better option once the engine, fuel system, transmission, cooling system, and calibration can take advantage of the larger frame.
Wheel Geometry: Why Shape Matters as Much as Size
Turbocharger performance cannot be determined by inducer and exducer diameter alone.
Blade count, blade depth, extended-tip design, hub size, weight, cutback, clipping, and the relationship between the compressor and turbine all influence how the turbocharger responds and flows.
The Pro Xe lineup demonstrates this clearly:
• The PX350 uses lightweight OEM-sized wheels to maximize response and efficiency.
• The PX380 uses a larger 7+7 compressor to increase airflow while maintaining street-friendly spool.
• The PX400 uses an 11+0 compressor and a more aggressively modified turbine system to maximize the K04’s usable flow range.
• The PX600 moves to the larger K16 frame because wheel changes alone cannot overcome every physical limitation of the K04 housing.
Arguments such as “7+7 is always better for top end” or “11+0 compressors always hurt high-RPM power” ignore the rest of the turbocharger system.
On the P1 K04 platform, the turbine wheel and housing become major restrictions as exhaust volume increases. Compressor-wheel geometry must therefore be selected around the turbine’s flow capacity, intended boost range, engine airflow, and desired response—not simply which wheel has the largest measurements.
Choosing Your Turbo
Choose the PX350 for maximum response, daily drivability, and strong street performance.
Choose the PX380 for the best overall balance of spool, torque, and top-end airflow.
Choose the PX400 when you want the highest possible performance from a K04-based turbocharger.
Choose the PX600 when your power goal and supporting modifications have moved beyond the practical limitations of the K04 frame.
The goal is not to install the largest turbo possible. The goal is to select the turbo that will operate most efficiently within the real-world requirements of your build.
